PVC CMYK Printing SLE5542/SLE5528 Smart IC Card
Model No. :CXJ-CIC-0004
Company:CXJ
Material :Paper, PVC or ECO material PET or ABS
Size: 85.5X54mm(3.375*2.125 inch)
Thickness: Standard 0.84mm,0.76-1mm is available
Printing:Glossy, matte or frosted
Card surface:Glossy, matte or frosted
Description
SLE5542/SLE5528 Smart IC Card:
Contact smart IC card is short for Integrated circuit card, the plastic embedded integrated circuit chips. Chips generally use the easy-volatile memory (ROM, EEPROM) to protect logic circuit, even with a microprocessor CPU . There are three types of smart IC card. Storage card or memory card; CPU smart IC cards; CPU super smart IC card with a monitor and keyboard. The advantage of smart IC card is large storage capacity, high security and easy to carry. It can be widely applied to many fields, such as mobile phone’s SIM cards, financial IC cards, access control cards, medicare cards, membership cards etc.
Smart IC Card Features :
1.Environmental protection of PVC material.
2.Safely.
3.Anti scratch, more durable with overlay and protect film.
Specification :
| Item | PVC CMYK Printing SLE5542/SLE5528 Smart IC Card | ||||||
| Material | Paper, PVC or ECO material PET or ABS | ||||||
| Dimension | ISO standard size CR80 85.5X54mm(3.375*2.125 inch)
Custom size and shape is also available |
||||||
| Thickness | ISO 0.84mm
0.76-1mm is available |
||||||
| Card surface | Glossy, matte or frosted | ||||||
| Printing | CMYK full color printing, silk printing or digital printing | ||||||
| Antennas | Aluminum or copper antenna | ||||||
| Contact IC chip model: | |||||||
| Brand | Chip Type | Specification | |||||
| Siemens | SLE4442/5542 | 256bit encryption card,can read data,write data and password,protect data and write password. | |||||
| ISO 7816 Compliant pad locations | |||||||
| 256*8 bit EEPROM organization | |||||||
| byte-wise addressing | |||||||
| Irreversible byte-wise write protection of lowest 32 addresses (byte 0-31) | |||||||
| 32*1 bit organization of protection memory | |||||||
| 2-wire link protocol | |||||||
| Answer to reset according to ISO standard 7816-3 | |||||||
| Programming time 2.5mS per byte for both erasing and writing | |||||||
| Minimum of 10000 write/erase cycles | |||||||
| Data retention > 10 years | |||||||
| Programmable Security Code (PSC) | |||||||
| Data write only after correct 3-byte PSC | |||||||
| SLE4428/5528 | ISO 7816 Compliant pad locations | ||||||
| 1024*8 bit EEPROM organization | |||||||
| byte-wise addressing | |||||||
| Irreversible byte-wise write protection of lowest 32 addresses (byte 0-31) | |||||||
| 32*1 bit organization of protection memory | |||||||
| 2-wire link protocol | |||||||
| Answer to reset according to ISO standard 7816-3 | |||||||
| Programming time 2.5mS per byte for both erasing and writing | |||||||
| Minimum of 10000 write/erase cycles | |||||||
| Data retention > 10 years | |||||||
| Programmable Security Code (PSC) | |||||||
| Data write only after correct 3-byte PSC | |||||||
| Shanghai
Fudan |
FM4442 | 256bit encryption card,can read data,write data and password,protect data and write password.(compatible SLE4442) | |||||
| FM24C16 | 16Kbit | ||||||
| FM4428 | 1024bit encryption card,can read data,write data and password,protect data and password operation.(compatible SLE4428) | ||||||
| Shanghai
Beiling |
BL7442 | 256bit | |||||
| BL24C04 | 4Kbit | ||||||
| ISSI | ISSI4442 | 256bit | |||||
| ISSI24C16 | 16Kbit | ||||||
| ISSI4428 | 8Kbit | ||||||
| ATMEL | AT24C01 | 1Kbit(stop production) | |||||
| AT24C02 | 2Kbit | ||||||
| AT24C04 | 4Kbit | ||||||
| AT24C16 | 16Kbit | ||||||
| AT88SC102 | 1Kbit | ||||||
| craft option | Barcode, magnetic stripe, injket number, thermal number,
laser number, embossing, hot stamping, signature panel, glossy lamination, hologram, UV spot, golden or silver background, scratch off panel, hole punching etc, QR code printing |
||||||
| UID code | Printing or laser numbering Decimal positive and inverse code Hexadecimal positive and inverse code |
||||||
| Working
temperature |
-25 degree to +50 degree | ||||||
| Reading&Writing
distance |
-2CM-5CM for LF & HF / 1m-6M (UHF), (Relative with reader.) | ||||||
| Application | Mobile phones
Ticketing & monetary transactions Turnstiles Vender Loyalty system for promotion -Parking meters -e-Payment Mobile payment, PayPal, Google Wallet, Ticketing, Boarding pass, Point of Sale, Coupons, Tour guide, Turnstiles, Vender, Parking meters, Loyalty system for promotion, etc. Gaming & toys |
||||||
| Package | For ISO CR80 size cards :
White Box: 6×9.3×22.5 cm 200 PCS /BOX Carton: 13x 23.5×50 cm, 10Boxes/CTN.Or on demand. 7KG/1000PCS |
||||||
| G.W: | For ISO CR80 standard cards:7KGS/1000pcs | ||||||
| Sample | Free sample for testing before order is available at any time | ||||||
| Other information: | |||||||
| Monthly output | 30,000,000pcs | ||||||
| Price term | FOB, CIF,CNF and EXW Factory | ||||||
| Payment term | we can accept Paypal or Escrow for sample order or small amount
50% T/T or Western Union deposit in advance, and 50% balance before shipment We also can accept L/C for bulk order |
||||||
| Lead time | Sample order:2-3 days after order confirmed
Quantity less than 500,000pcs：7-10 days after order confirmed Quantity over than 500,000pcs: 12-15 days after order confirmed |
||||||
| Warranty: | we can offer re-make free if any quality problem | ||||||
| Disclaim:
The showing picture is only for your reference of our product. All related to intellectual property rights of trademark belong to trade mark companies |
|||||||
